LCD Monitor | 8.4 |
Model | G084SN03 V3 |
Resolution (pixel) | 800*600 |
Active Area(mm) | 170.4(H) x 127.8(V) |
Pixel Pitch (mm) | 0.213x 0.213 |
Mode | TN,Normally White |
Number of Colors | |
Support Color | 262K(6-bit) / 16.2M(8-bit) |
Color Saturation (%) | 45% |
View Angle (H/V) | 80/80/80/60 |
Brightness (nit) | 250cd/m2 |
Contrast Ratio | 600:1 |
Response Time(ms) | 35 |
Power Consumption (W) | TBD |
Interface | 1 channel LVDS |
Supply Voltage (V) | 3.3 |
Backlight | LED |
V x H x T (mm) | 203.0(W) x 142.5(H) x 5.7(D) (typ.) |
Weight(g) | TBD |
Production | Now |
Remark | -20℃~+70℃ |
